The John Deere Z515E ZTrak Zero-Turn Mower delivers dependable residential cutting performance built on a rugged, heavy-duty frame designed for properties up to 2 acres. Powered by a 24 HP (17.9 kW) V-twin engine displacing 726 cc, it pairs reliable output with dual sealed Tuff Torq TZT7-M hydrostatic transmissions that provide responsive maneuverability and enhanced hillside stability.
Equipped with a 121.9 cm High-Capacity mower deck stamped from durable 9-gauge steel, this machine ensures superior airflow and even clipping distribution across varied terrain. Heat-treated 2.5 cm cold-forged spindles supported by ball bearings deliver commercial-grade durability, while an easy-fold Roll-Over Protective Structure and mid-back seat with armrests provide exceptional operator comfort and security.
Key Features
| Brand | John Deere |
| Model | Z515E |
| Product Type | Zero-Turn Mower |
| Cutting Width | 121.9 cm |
| Engine Horsepower | 24 HP (17.9 kW) |
| Engine Displacement | 726 cc |
| Engine Type | V-Twin |
| Transmission Type | Dual Tuff Torq TZT7-M Unitized Hydrostatic |
| Maximum Forward Speed | 12.1 km/h |
| Deck Material | 9-gauge (3.8 mm) Steel |
| Spindle Size | 2.5 cm Cold-Forged Heat-Treated |
| Seating | Mid-Back with Armrests |
| Roll-Over Protection | Easy-Fold ROPS |
| Shipping Weight | 350 kg |
Highlights
- Hinged, raisable plastic deflector for compact storage
- Adjustable mower wheels to reduce scalping
- Standard front rollers and double-captured wheels for even mowing
- Low-set transmissions for hillside stability
- Easy-fold ROPS for storage in low-clearance spaces
- Optional rear hitch for towing attachments
- Compatible with optional MulchControl™ kit and 6.5-bu Power Flow™ rear bagger
- 4-year / 500-hour single-source bumper-to-bumper warranty (transferable)
Compatibility
Compatible with the optional MulchControl kit, 229-liter (6.5-bushel) Power Flow rear bagger, and optional rear towing hitch attachments.
Warranty
4-year full manufacturer warranty included, covering all parts and defects in materials and workmanship. 4-year / 500-hour single-source bumper-to-bumper warranty (transferable).
